Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

BAIC 2.0L TD (DCM6.2AP) [RD/WR/CK]
BAIC 2.0L TD EEPROM (DCM6.2AP) [RD/WR]
Changan 2.0L TD (DCM7.1AP) [RD/WR/CK]
Dongfeng 2.3L TD (DCM7.1AP) [RD/WR/CK]
Dongfeng/Yuchai 2.4L TD (DCM7.1AP) [RD/WR/CK]
Great Wall/Haval 2.0L TD (DCM6.2AP) [RD/WR/CK]
Great Wall/Haval 2.0L TD (DCM7.1AP) [RD/WR/CK]
Great Wall/Haval 2.0L TD EEPROM (DCM7.1AP) [RD/WR]
JAC 2.0L TD (DCM6.2AP) [RD/WR/CK]
JAC 2.0L TD EEPROM (DCM6.2AP) [RD/WR]
Jiangling/Isuzu 2.8L TD (DCM7.1AP) [RD/WR/CK]
Qingling/Isuzu 3.0L TD (DCM6.2AP) [RD/WR/CK]
Qingling/Isuzu 3.0L TD (DCM7.1AP) [RD/WR/CK]
SsangYong: 2.2L XDI (DCM6.2AP/6D/S2) [RD/WR/CK]
SsangYong: 2.2L XDI (DCM6.2AP/6D/S2) EEPROM [Test] [RD/WR]
Trucks (DCM6.24) [Test] [RD/WR/CK]
Foton/Vanche/Yuchai 2.4L TD (DCM7.24) [RD/WR/CK]
Foton/Vanche/Yuchai 2.4L TD EEPROM (DCM7.24) [RD/WR]
Foton/Yuchai 4.2L, 4.3L TD (DCM7.24) [RD/WR/CK]
Foton/Yuchai 4.2L, 4.3L TD EEPROM (DCM7.24) [Test] [RD/WR]
JCB 4.4L TD (DCM2.7AP) [RD/WR/CK]
JCB 4.4L TD EEPROM (DCM2.7AP) [Test] [RD/WR]
JCB 4.4L, 4.8L TD (DCM7.24) [RD/WR/CK]
JCB 4.4L, 4.8L TD EEPROM (DCM7.24) [RD/WR]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Delphi DCM6.2AP/DCM6.24 / Delphi DCM7.1AP/DCM7.24 / Delphi DCM2.7AP
• Connection type: Bench / OBD Mode
• Connection diagram: PCMflash diagram (PDF)
