Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

Ashok Leyland TD (DCM2.5) [RD/WR/CK]
Ashok Leyland 1.5L TD (DCM7.1AP) [RD/WR/CK]
Ashok Leyland LCV TD (DCM7.1AP) [RD/WR/CK]
Eicher E366/E474 2.0L, 3.0L TD (DCM7.1AP) [RD/WR/CK]
Force 2.6L TD (DCM2.7AP) [RD/WR/CK]
Force 2.6L TD EEPROM (DCM2.7AP) [RD/WR/CK]
Force Motors 2.6L TD (DCM7.1AP) [RD/WR/CK]
Kia/Hyundai 1.6L TD (DCM7.1AP) [RD/WR/CK]
Mahindra TD (DCM2.5) [RD/WR/CK]
Mahindra 1.6L TD (DCM2.7AP) [RD/WR/CK]
Mahindra 1.6L TD EEPROM (DCM2.7AP) [Bench] [RD/WR]
Mahindra 1.5L TD (DCM7.1AP) [RD/WR/CK]
Mahindra 1.5L TD EEPROM (DCM7.1AP) [Boot] [RD/WR]
Tata TD (DCM2.5/DCM2.5P) [RD/WR/CK]
Tata 1.5L TD (DCM7.1AP) [RD/WR/CK]
Tata LCV TD (DCM7.1AP) [RD/WR/CK]
Tata Truck TD (DCM7.24) [RD/WR/CK]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Delphi DCM2.5/DCM2.5P/DCM2.7AP / Delphi DCM7.1AP/DCM7.24
• Connection type: Bench / OBD Mode
• Connection diagram: PCMflash diagram (PDF)

Notes

• Boot / Recovery connection is shown for DCM7.1AP in the official guide. Use the procedure and function flags specified for the selected protocol.
