PCMflash Module 94 – Aisin TCU Bootloader
Code: DJ-PCMF-M094
$225.00
Aisin SH705x TCU / Aisin D70F4019 TCU / Aisin R7F7012xx TCU. Bench Mode only. Functions: read, write, checksum correction/verification.
Loading
- Delivery Software, no physical shipping
- Category PCMflash software modules
- Questions WhatsApp · Email us
Description
Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.
Supported protocols
Aisin SH705x TCU (FLASH) [RD/WR/CK]
Aisin SH705x TCU (EEPROM) [RD/WR]
Aisin D70F4019 TCU (FLASH) [RD/WR/CK]
Aisin D70F4019 TCU (EEPROM) [RD/WR]
Aisin R7F7012xx TCU (FLASH) [RD/WR/CK]
Aisin R7F7012xx TCU (EEPROM) [RD/WR]
RD = read · WR = write · CK = checksum correction/verification
Connection
- Supported ECUs/TCUs: Aisin SH705x TCU / Aisin D70F4019 TCU / Aisin R7F7012xx TCU
- Connection type: Bench Mode only
- Connection diagram: PCMflash diagram (PDF)
