Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

MD1/MG1 FLASH (SPC572L/SPC574K/SPC5777M/SPC58/TC275TP/TC277TP/TC298TP/TC299TP/TC387QP/TC399XP) [RD/WR/CK]
MD1/MG1 EEPROM (SPC572L/SPC574K/SPC5777M/SPC58/TC275TP/TC277TP/TC298TP/TC299TP/TC387QP/TC399XP) [RD/WR]
MG1UA008/MG1US008 FLASH (SPC574K/TC277TP) [RD/WR/CK]
MG1UA008/MG1US008 EEPROM (SPC574K/TC277TP) [RD/WR]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Bosch MD1/MG1 / Bosch MG1UA008/MG1US008
• Connection type: Bench Mode only
• Connection diagram: PCMflash diagram (PDF)

Notes

• Operation requires a direct connection to the ECU connector and a Scanmatik 2/Scanmatik 2 Pro or Dialink adapter.
• ECUs manufactured after mid-2020 may not be supported.
