Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

R7F701202/R7F701216 P5-UDS [RD/WR/CK]
LC300/LX500d 3.3TD P5-UDS (F33A-FTV/R7F701216) [RD/WR/CK]
LC300/LX500d 3.3TD MCU #2 P5-UDS (F33A-FTV/R7F701216) [RD/WR/CK]
LC150/Hiace/Hilux/Revo/Fortuner 2.4TD, 2.8TD P5-UDS (1GD-FTV/2GD-FTV/R7F701216) [RD/WR/CK]
LC150/Hiace/Hilux/Revo/Fortuner 2.4TD, 2.8TD 6AT Gearbox P5-UDS (AC60F/R7F701201) [RD/WR/CK]
Camry/ES/Rav4/UX 2.0L, 2.5L P5-UDS (M20A-FKS/A25A-FKS/R7F701202) [RD/WR/CK]
Camry/ES/Rav4 2.5L 8AT Gearbox P5-UDS (UB80/R7F701201) [RD/WR/CK]
Camry/ES/Rav4 2.5L HV P5-UDS (A25A-FXS/R7F701202) [Test] [RD/WR/CK]
Corolla 2.0L P5-UDS (M20A-FKS/R7F701202) [RD/WR/CK]
Highlander/Siena 2.5L HV P5-UDS (A25A-FXS/R7F701216) [Test] [RD/WR/CK]
NX250 2.5L P5-UDS (A25A-FKS/R7F701216) [RD/WR/CK]
Yaris GR 1.6T P5-UDS (G16E-GTS/R7F701216) [Test] [RD/WR/CK]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Denso/Renesas R7F701201 / Denso/Renesas R7F701202 / Denso/Renesas R7F701216
• Connection type: Bench / OBD Mode
• Connection diagram: PCMflash diagram (PDF)
