Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

ME9/MED9/EDC7/EDC16/PSG16/TCU (MPC556/MPC562/MPC564) [RD/WR/CK]
ME9/MED9/EDC7/EDC16/PSG16/TCU MICRO (MPC556/MPC564) [RD/WR/CK]
ME9/MED9/EDC7/EDC16/PSG16/TCU EXT (MPC556/MPC562/MPC564) [RD/WR/CK]
ME9/MED9/EDC7/EDC16/PSG16/TCU EEPROM (MPC556/MPC562/MPC564) [RD/WR]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Bosch ME9/MED9/EDC7/EDC16/PSG16/TCU
• Connection type: Bench Mode only
• Connection diagram: PCMflash diagram (PDF)

Notes

• Operation requires a direct connection to the ECU connector and either a Scanmatik 2/Pro adapter or "Powerbox for PCMflash" together with one of the tested adapters.
• Some RE5RO5A variants require additional GPT contact access. Follow the exact TCU diagram, including any access or opening instructions.
