Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

SH725xx FLASH [RD/WR/CK]
SH725xx EEPROM [RD/WR]
1N83M FLASH [RD/WR/CK]
1N83M EEPROM [RD/WR]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Denso SH725xx/1N83M
• Connection type: Bench Mode only
• Connection diagram: PCMflash diagram (PDF)

Notes

• Operation requires a direct connection to the ECU connector!
