Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

MEDC17 (TC1762/1766/1792/1796) FLASH [RD/WR/CK]
MEDC17 (TC1762/1766/1792/1796) EEPROM [RD/WR]
MEDC17 (TC1724/1728/1767/1782/1784/1797) FLASH [RD/WR/CK]
MEDC17 (TC1724/1728/1767/1782/1784/1797) EEPROM [RD/WR]
MEDC17 (TC1791/1793) FLASH [RD/WR/CK]
MEDC17 (TC1791/1793) EEPROM [RD/WR]
MEDC17 BSL PASSWORD [RD]
EDC17C06 EEPROM (8KB) [RD/WR]
EDC17CV41 EEPROM (32KB) [RD/WR]
MEV17.2 EXT EEPROM (8KB) [RD/WR]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Bosch ME17 / MED17 MEDG17 / MEV17 / MEVD17 / MEDC17 / EDC17 / DCU17
• Connection type: Bench Mode only
• Connection diagram: PCMflash diagram (PDF)

Notes

• Operation requires a direct connection to the ECU connector and a Scanmatik 2/Pro/3 adapter.
