Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

76F0196/198/199/219 Bootloader [RD/WR/CK]
76F0196/198/199/219 Bootloader EEPROM [RD/WR]
76F0199 Gearbox Bootloader [RD/WR/CK]
76F0199 Gearbox Bootloader EEPROM [RD/WR]
76F0196/198 HV Control Bootloader [RD/WR/CK]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Denso 76F0196/76F0198/76F0199/76F0219
• Connection type: Bench Mode only
• Connection diagram: PCMflash diagram (PDF)

Notes

• Requires a direct connection to the ECU connector, a boot/bench cable or a "Powerbox for PCMflash" device (or equivalent) for automatic control of power and "boot" pins, and a Scanmatik 2/Pro/3, Mongoose Pro MFC, or Tactrix Openport 2.0 adapter.
• Add-on module for Toyota/Lexus/Scion/Hino Generation 2.
