Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

Mazda: 1.5L, 2.0L, 2.5L SKYACTIV-G P5/PE/PY (Mazda3/CX5/6 Mitsubishi) [RD/WR/CK]
Mazda: 2.5T SKYACTIV-G PY (Mazda CX9 Mitsubishi) [RD/WR/CK]
Mazda: 1.5L, 2.0L, 2.5L SKYACTIV-G P5/PE/PY (Mazda3/CX5/6 Denso) [RD/WR/CK]
Mazda: 1.5L, 2.0L, 2.5L SKYACTIV-G P5/PE/PY (Mazda3/CX5/6 Denso Crypted) [RD/WR/CK]
Mazda: 2.2L SKYACTIV-D SH (Mazda3/CX5/6 Denso) [RD/WR/CK]
Mazda: 2.2L SKYACTIV-D SH (Mazda3/CX5/6 Denso Crypted 2MB) [RD/WR/CK]
Mazda: 1.5L, 2.2L SKYACTIV-D S5/SH (Mazda2/3/CX5/6 Denso Crypted 3.75MB) [RD/WR/CK]
Mazda: 1.6L Z6 (Denso) [RD/WR/CK]
Mazda: 1.6L Z6 (Denso Crypted) [RD/WR/CK]
Mazda: 1.5L, 2.2L SKYACTIV-D S5/SH (Mazda2/3/CX5/6 Denso 3.75MB) [RD/WR/CK]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: Mitsubishi Electric Mazda PCM / Denso Mazda PCM
• Connection type: Bench / OBD Mode
• Connection diagram: PCMflash diagram (PDF)
