Requires a PCMflash USB dongle. Send your dongle serial number with the order at checkout. One dongle can hold any number of modules.

Supported protocols

Ford Focus 3: 1.6L Sigma Ti-VCT (EMS2204) [RD/WR/CK]
Ford Focus 3: 2.0L Duratec GDI Ti-VCT (MED17) [RD/WR/CK]
Ford Focus 3 ST: 2.0L Ecoboost GTDI (MED17) [RD/WR/CK]
Ford Focus 3: 1.6L, 2.0L PowerShift TCM (6DCT250) [RD/WR/CK]

RD = read · WR = write · CK = checksum correction/verification

Connection

• Supported ECUs/TCUs: EMS2204 and MED17 engine ECUs; 6DCT250 PowerShift transmission control module.
• Connection type: Bench / OBD Mode
• Connection diagram: PCMflash diagram (PDF)

Notes

• The official Bench diagram covers the 6DCT250 PowerShift TCU. EMS2204 and MED17 engine protocols are listed in OBD Mode.
